SMT Lösung zur Überwachung der Geräte

The monitoring system is one of the most widely used systems in the security system.

For Monitroing Equipment Production, we can provide full SMT and DIP line Machine for PCB Assembly.

The most suitable site monitoring system on the market now is the handheld video communication equipment, and video monitoring is now the mainstream. From the earliest analog monitoring to digital monitoring and then to network video monitoring, earth-shaking changes have taken place.

Today, IP technology is gradually unified around the world. From the perspective of SMT technology, let's take a look at PCB assembly of monitoring equipment.

Video Signal Acquisition card PCBA

Monitoring Equipment PCBA

Camera PCBA

SMT is short for Surface Mount Technology.

It is a circuit assembly technology that directly mounts surface mount components on the PCB (Printed Circuit Board) without through holes, and solders them to the specified position on the surface of the printed circuit board.

SMT Process:  Solder Paste (Red Glue) Printing --> Components Mounting --> Reflow Soldering --> AOI Optical Inspection

Economical full-auto SMT Line equipment as follows: : 1 person to operate the whole line, 1 person to test AOI, total 2 people.

What is DIP ?

DIP is short for Dual In-line Package.

It is a type of component package. But it is traditionally used to refer to THT (Through Hole Technology).

It is a circuit assembly technology that inserts the component lead into the reserved through hole on the PCB, temporarily fixes and welds it on the other side of the substrate to form a reliable welding spot.
